Triaxial Compression/Extension testing devices Dü16 - Dü19

kind of experiments:	TC, TE, TCc, TEc, TCH
axial pressure:	0-200 MPa, hydraulic
confining pressure:	0-200 MPa, hydraulic
temperature:	-20 to +100°C, automatically controlled
examined body:	diameter 60-100 mm, length 120-250 mm
measurement recording:	computer controlled, MGC+
measurement recorder:	1 x displacement transducer W20TS/ W50TS 3 x pressure sensor P3MB, 50 MPa 3 x Pt100 1 x dilatancy measurement 1 x ultrasonic wave velocity measurement
